BUILDING BLOCK - Deployable Data Package

Description	A Deployable Data Package represents a data part of an Application that must be hosted and accessed by application services (code) to run. Each Deployable Data Package is associated to Required Software Technologys (for data hosting and access) and can host several data structures. Architect can also prescribes a kind of hosting artefact (IaaS/PaaS cloud service or IT server model).
External references	C4 Model - Level 2 - Container Diagram
Super Types	Deployable Package
Functional Domain	Application Deployment Architecture The Application Deployment Architecture domain defines concepts used to organize Applications in Deployable Packages.
Dictionary	Dictionary of SysFEAT concepts
Framework Mapping	C4 Model Mappings : Container Database

RELATIONSHIPS

Simple Graph Graph & Inheritance Table

Simple Graph

Composition: ➝ Classification: ➝ Specialization: ➝ Enumerated definition: ➝ Syntax: ➝

Graph & Hierarchy

Composition: ➝ Classification: ➝ Specialization: ➝ Enumerated definition: ➝ Syntax: ➝

Relationship Table

Relationship	Cardinality	Target Entity	Source Entity	Description
Technical Data Store	[*..0]	Physical Data Domain	Deployable Data Package	A technical data store represents the usage of a physical data area in a technical data area of the technical architecture of an application.
Specialized Package	[*..0]	Deployable Package	Deployable Package
Packaged Application	[1..1]	Application	Deployable Package
Required Software Technology	[*..0]	Software Technology	Deployable Package
Specialized Business Operating Agent	[*..0]	Resource Agent	Resource Agent

TEXTUAL SYNTAX

SEMANTIC TAXONOMY

Sub-Types Super-Types

Click node rectangle to collapse/expand one level. Click triangle for full recursive collapse/expand. Double-click on a node to open its URL. Hover for description.

BORDERS

Name	Super type	Border Type	Description
Physical Client Point	Technology System::Technology Request Point	Physical Software Interface	A technical output port is a point that allows asking to open a communication line from a technical architecture or an application technical area and that complies with a specified communication protocol (SMTP, HTTP, etc.).
Physical Service Point	Technology System::Technology Service Point	Physical Software Interface	A Physical Service Point is a connection point allowing opening a communication to a technical architecture or an application technical area that complies with a specified communication protocol (SMTP, HTTP, etc.).
